ZC-L-850
ZC-L Series

ZC-L-850

ZC-L-850 provides 850 W output with 24/36/48 Vdc support and IP67 protection. It is designed for golf carts, sweepers, and light-duty industrial vehicles.

850 W24/36/48 VdcIP67
Request a Quote Technical Support

Product Overview

ZC-L-850 provides 850 W output with 24/36/48 Vdc support and IP67 protection. It is designed for golf carts, sweepers, and light-duty industrial vehicles. Input range: 85-264 Vac. Output specification: 24 Vdc, 36 Vdc, 48 Vdc. Typical efficiency: Up to 93%. Communication interface: CAN 2.0B / J1939, USB.

About the ZC-L Series

Z-Linx Lite-Power ZC-L Series supports 400 W to 2.0 kW on-board charging for compact electric vehicles and light industrial equipment.

Technical Specifications

USB Functions firm ware programming, curve adjustment, log reading
Input Voltage 85-264 Vac
Output Voltage Options 24 Vdc, 36 Vdc, 48 Vdc
Example Outputs 24V / 36A, 36V / 22.5A, 48V / 18A
Rated Output Power 850 W
Efficiency Up to 93%
Enclosure IP67 rated
Communication CAN 2.0B / J1939, USB
Operating Temperature -20°C to +55°C
Storage Temperature -40°C to +85°C
Dimensions 195 x 177 x 160 mm
Weight 4.5 kg

OEM Procurement Signals

For sourcing teams searching on-board charger manufacturer, on-board charger supplier, and on-board charger oem, this section translates ZC-L-850 specs into procurement decision inputs.

  • ZC-L-850 is offered through OEM programs for teams evaluating on-board charger manufacturer and on-board charger supplier options.
  • Commercial intake supports on-board charger quotation and on-board charger price requests based on configuration and annual volume.
  • Engineering response includes on-board charger datasheet details, integration notes, and validation checkpoints.
  • Application focus: micro mobility and light industrial vehicle programs.

Integration Checklist

Engineering teams evaluating on-board charger can protocol and on-board charger ip67 requirements can use this checklist before RFQ and pilot deployment.

  • Power class: 850 W; output profile: 24/36/48 Vdc.
  • Input range: 85-264 Vac; communication interface: CAN 2.0B / J1939, USB.
  • Protection level: IP67 rated; suitable for on-board charger ip67 filtering workflows.
  • System focus: compact charger integration with BMS, CAN diagnostics, and IP-rated installation.

Recommended Technical Paths

ZC-L-850 FAQ

How can I request on-board charger quotation for ZC-L-850?

Use the contact page and provide target voltage, battery chemistry, annual volume, and delivery window. The team will return a project quotation for ZC-L-850.

Can ZC-L-850 support on-board charger can protocol?

ZC-L-850 supports CAN 2.0B / J1939, USB. Integration parameters can be aligned with your BMS and controller mapping during project review.

How do I obtain on-board charger datasheet information for engineering review?

on-board charger datasheet packages are shared through the contact workflow and include electrical characteristics, interface notes, and integration guidance.

Is on-board charger price published as a fixed list price?

No fixed list price is published. on-board charger price is provided by quotation because power level, cooling layout, and harness options differ by project.

Related Models in ZC-L Series

Compare adjacent models in the same product family.

Ready to evaluate ZC-L-850?

Contact our team for quotation, lead time, and integration support for ZC-L-850.

Inquire ZC-L-850
